GISL-42R self-balanced throw screens
The screens are designed for screening and classification of bulk materials, dewatering, slim removal and suspension washing-off from concentrates with bulk density up to 2,8 t/mi.
Technical specifications GISL-42R
|
Parameters |
GISL-42R |
|---|---|
|
Feeding lumps size, mm, not more |
200 |
|
Feedstock output, t/h |
1 700 |
|
Screening surface type: |
is defined by the producer |
|
Slot width (lower sieve), mm |
accord. customer RS |
|
Screening surface dimensions, mm |
5 635 x 1 500 |
|
Active area of one sieve, m2 |
8,45 |
|
Number of screening surfaces |
2 |
|
Screening angle, grad. |
0...30 |
|
Engine installed power, kW |
2x15 |
|
Frame vibration amplitude, mm |
3...7 |
|
Frame vibration frequency, min-1 |
730 |
|
Overall dimensions of screen vibrating part, mm, not more |
5 635 x 2 150 x 2 100 |
|
Mass, without spare parts, kg, not more |
4 830 |
