GISL-62R self-balanced throw screens
The screens are designed for screening and classification of bulk materials, dewatering, slim removal and suspension washing-off from concentrates with bulk density up to 2,8 t/mi.
Technical specifications GISL-62R
|
Parameters |
GISL-62R |
|---|---|
|
Feeding lumps size, mm, not more |
300 |
|
Feedstock output, t/h |
460 |
|
Screening surface type: |
is defined by the producer |
|
Slot width (lower sieve), mm |
accord. customer RS |
|
Screening surface dimensions, mm |
5 670 x 2 000 |
|
Active area of one sieve, m2 |
11,3 |
|
Number of screening surfaces |
2 |
|
Screening angle, grad. |
0...25 |
|
Engine installed power, kW |
2x15 |
|
Frame vibration amplitude, mm |
4,8...7,4 |
|
Frame vibration frequency, min-1 |
735 |
|
Overall dimensions of screen vibrating part, mm, not more |
5 670 x 2 670 x 2 500 |
|
Mass, without spare parts, kg, not more |
7 100 |
