GIT-72 unbalanced-throw screens of heavy-duty type
The unbalanced-throw screens of heavy-duty type are designed for dry screening of ores of ferrous and non-ferrous metals and other bulk materials. The material can be devided in 2,3,4 types of sizes.
The construction of the vibrator shaft is changed, which allows to quickly change the location of the drive without reassembling the vibrator itself (the half-coupling is attached directly to the unbalance).
|
Parameters |
GIT-41A |
|---|---|
|
Feeding lumps size, mm, not more |
300 |
|
Bulk density, t/m3, not more |
2,7 |
|
Feedstock output, t/h |
1 200 |
|
Screening surface type - Lower |
wire sieve with meshes sizes, mm |
|
Dimensions of screening surface, mm |
4 200 x 2 100 |
|
Active area of one sieve, m2 |
8,8 |
|
Number of screening surfaces |
2 |
|
Screening angle, grad. |
20 |
|
Engine installed power, kW |
18,5 |
|
Frame vibration amplitude, min-1 |
3-8 |
|
Frame vibration frequency, min-1 |
1 470 |
|
Overall dimensions of screen vibrating part, mm, not more |
4 810 x 2 800 x 1 290 |
|
Mass, kg, without engine, cover |
5 500 |
