Amurets-100 (Амурец-100) drilling rig
Amurets-100 (Амурец-100) drilling rig is designated for boring vertical holes with the diameter of 6 inches and depth of up to 100 m from open surface when carrying out prospecting surveys, engineering surveys and detailed exploration of mineral resource deposits in soft grounds and solid rocks.
Hereby we offer supply of drilling tools of Amurets-100 (Амурец-100) rig!
|
Name |
No. of drawing |
Weight, kg |
|---|---|---|
|
Operating drilling tools |
Б265.02.00.000 |
|
|
Rig assembly (rod, pony rod lock) |
|
500,0 |
|
Drill stem (L=3115 mm.) |
Б265.02.00.001 |
252,0 |
|
Drill stem (L=4000 mm.) |
Б265.02.00.001 |
336,0 |
|
Pony rod (L=3115 mm.) |
Б265.02.00.001-01 |
216,0 |
|
Pony rod (L=2000 mm.) |
Б265.02.00.001-01 |
168,0 |
|
Light flat bit |
Б265.02.00.002 |
43,0 |
|
Four-point bit (casing of bit) Ø 140 |
Б265.02.00.003 |
70,0 |
|
Heavy flat bit |
Б265.02.00.004 |
73,5 |
|
Big shield cap |
Б265.02.00.005 |
5,0 |
|
Big safety plug |
Б265.02.00.006 |
0,3 |
|
Adapter (L=400 mm.) |
Б265.02.00.007 |
24,5 |
|
Adapter (L=400 mm.) |
Б265.02.00.008 |
21,5 |
|
Small safety plug |
Б265.02.00.009 |
0,1 |
|
Rotary jar |
Б265.02.00.010 |
113,0 |
|
Small shield cap |
Б265.02.00.011 |
4,1 |
|
Tool wrench |
Б265.02.00.012А |
29,5 |
|
Sleeve of wire-rope socket |
Б265.02.00.018 |
1,0 |
|
Wire-rope socket |
Б265.02.00.020 |
31,0 |
|
Drilling clamp |
Б265.02.00.030 |
|
|
Piston bailer Ø 130 |
Б265.02.01.000 |
42,0 |
|
Chain lever |
Б265.02.02.000 |
17,5 |
|
Bailing line Ø 11,0 |
|
|
|
Left-lay tool line Ø 19,5 |
|
|
|
Casing pipes and fitting thereto |
Б265.05.00.000 |
|
|
Casing shoe ø 144, L = 210 |
Б265.05.00.001 |
7,5 |
|
Boring pipe (casing pipe), 2.1 m |
Б265.05.00.002 |
92,5 |
|
Casing drive head |
Б265.05.00.003 |
11,0 |
|
Drive-out head |
Б265.05.00.004 |
20,3 |
|
Safety plug |
Б265.05.00.005 |
3,5 |
|
Shield cap |
Б265.05.00.006 |
3,9 |
|
Drive hammer |
Б265.05.00.010 |
36,0 |
|
Drive hammer bolt |
Н-002-64 |
5,0 |
|
Drive hammer nut |
Н-006-64 |
1,0 |
|
Drive-out split head |
Б265.05.00.020 |
19,5 |
|
Drive-out hammer |
Б265.05.00.030 |
6,5 |
|
Piper holder |
Б265.05.00.040 |
18,0 |
|
Hinged-jaw tongs KSh-168 (КШ-168) |
Б265.05.00.050 |
10,0 |
|
Clamp |
Б265.05.00.060 |
35,0 |
|
Pin of drive-out head |
Б265.05.00.070 |
1,3 |
|
Drive clamp |
Б265.05.01.000 |
19,5 |
|
Emergency tools |
Б265.00.20.000 |
|
|
Bell socket |
Б265.00.20.010 |
47,6 |
|
Spear |
Б265.00.20.020 |
27,5 |
|
Bowl slip socket (pipe head) |
Б265.00.20.030 |
31,0 |
|
Hammer assembly |
Б265.00.20.040 |
100,0 |
|
Fishing tongs |
Б265.00.20.050 |
113,0 |
By contacting the company Mining Machines JSC, you can lease special equipment for various purposes. We have prepared a special package of leasing programs for small and medium-sized businesses and individual entrepreneurs. Please fill out the form and find out about the conditions.
