SMPA, SMPA-M and SMPA-TM Suspended guard magnets

Self-dumping suspended guard magnets of SMPA series with ‘standard’ magnetic systems, SMPA-M with more powerful magnetic systems and SMPA-TM series comparable with electromagnetic guard magnets by their power don't require frequent attention from service personnel, are often applied in automatic and automated lines

The depth of removal area is one of the main quality parameters of suspended guard magnets. Unique magnetic systems ensure the removal of strong magnetic inclusions from the distance up to 450 millimeters from the operating surface of the guard magnet!

Unique patented magnetic systems on permanent magnets ensure long effective operation of guard magnets. The guaranteed retention life of magnetic system features as long as operation conditions are observed is 10 years.

Thanks to the magnetic systems on permanent magnets, SMPA and SMPA-M and SMPA-TM guard magnets do not consume electrical power to generate a magnetic field and differ from their electromagnetic equivalents by the considerably higher operational reliability.

Guard magnets of SMPA-TM series are intended for operation in extremely difficult conditions – due to the powerful magnetic systems, they are capable to remove especially large metal inclusions with the weight up to 40 kg from material flows the and provide effective recovery even at a high speed of material transportation (with belt speed to 3 m/s).
